Mobile oxygen concentrator MO₂-10 + Air + suction set

Fields of use:

Details:

• basic unit, papyruswhite RAL 9018, sound- and vibration insulation, mobile due to four lock and swivelling castors
• front control panel with main switch for oxygen and air
• 2 operation time counters
• temperature alarm with automatic shut-off to avoid overheating
• oxygen monitor
• 2 pressure gauges
• built-in compressed-air piston compressor (oil-free) with air intake filter (99,999%) for oxygen and built-in compressed-air piston compressor (oil-free) for air
• radial ventilator
• oxygen booster
• 10 l air and 10 l oxygen storage tank with pressure control and automatic switch for continuous stand by regulation
• oxygen PSA-module ATF, (maintenance free, for a continuous operation)
• suction venturi
• suction bottle
• one way suction bag
• slide-in unit for segment suction
• 2 additional oxygen outputs equipped with flowmeter and humidifier

Technical Data:

Oxygen concentration:

1-10 l/min 93% +/-3%

Oxygen pressure:

5.0 bar (constant)

Air capacity:

40 l/min

Air pressure:

5.0 bar (constant)

Mains voltage:

230 V 50 Hz +/-10%

Power consumption:

1560 Watt, 8 Ampere

Noise level:

60 dB (A)

Guarantee:

1 year

CE-mark

Technical information is subject to change without notice!
